UNIV®-SM Stone Adhesive

Description
UNIV®-SM Stone Adhesive is a pre-mixed, ready-to-use adhesive compound with a grey base and high-quality silica (SiO2 98%+), cement, and adhesive components. Designed for both internal and external applications, it ensures consistent quality for all types of natural stone fixing. UNIV®-SM is a single-component, water-resistant bonding mixture ideal for civil construction projects.

Reference Standard
  • IS:15477
  • EN-1348

Area of Application
UNIV®-SM can be used for various types of
  • Ceramic tiles
  • Bricks
  • Vitrified tiles
  • Natural stones
  • Marble
  • Granite
  • Terracotta
  • Large format tiles
  • Porcelain
in accordance with IS 13712: 2006. Suitable for flooring and walls in both internal and external areas, it is effective in dry and wet conditions for domestic and commercial applications.

Benefits
  • High Compressive Strength: Achieves compressive strengths of 12.1–14.5 MPa in 2 days, 19.1–23.8 MPa in 7 days, and 34.1–36.9 MPa in 28 days, depending on the aerogel content ratios and activator dosages.
  • Easy Application: Pre-mixed material requires only the addition of water on-site, simplifying and speeding up the stone fixing process.
  • Self-Curing Properties: The silica-based compound ensures low temperature of the bonding agent and fast curing, allowing hassle-free application with minimal labor.
  • Better Coverage: Provides efficient and effective coverage for various applications.
  • Eco-Friendly: Contains no fly ash or slag.
Technical Information KJ & KJ+
Dry Bulk Density 1300-1450 Kg/m3
Water powder ratio 20% to 22% by weight
Fresh Wet Density 1700-1800 Kg/m3
Open time (IS 15477:2019) Approx. 20 minutes
Adjustability (IS 15477:2019) Approx. 20 minutes
Compressive strength > 12.1 to 14.1 Mpa SM@ 7 Days
> 34.1 to 36.9 Mpa SM@ 28 Days
Tensile adhesion strength as per (IS 15477:2019) ≥ 0.7 N/ mm2
Pull Out adhesion strength as per (IS 15477:2019) ≥ 1.5N/ mm2 @ 7 Days
≥ 3.5 N/ mm2 @ 28 Days
Application temperature (substrates & materials) 5°C to 35°C
Adhesive thickness of Layer 3 mm – 12 mm
Pot life 2.0 Hr @ 30 C
Settings/ trafficable time 24 hours

Coverage Table
      Size of Bag Adhesive thickness of Layer Area of Coverage
20 Kg 3mm 65 to 70 Sq. Feet
20 Kg 5mm 38 to 40 Sq. Feet
20 Kg 6mm 30 to 33 Sq. Feet
20 Kg 8mm 23 to 25 Sq .Feet
(using 6 mm x 6 mm notch)

Shelf Life- It has a shelf life of 12 months from the date of manufacture. Store at cool and dry place.

Packing Size- 20 Kg Bag Size

Limitations or Restrictions
  • Avoid direct application to gypsum plaster or boards, fiber cement boards, drywall partitions, plywood, chipboard, particleboard, decorative laminates, resilient flooring, metal, plastic, deformable surfaces, or surfaces subject to vibrations.
  • Not suitable for fixing artificial, nano, engineered stone, composites, or metal tiles.

How toApply: -
Surface Preparation
Prepare the surfaces before the UNIV®-SM application by removing oil, bond inhibiting agents, dirt, dust and laitance
The cleaning can be carried out with suitable methods like by using wire brush, water jetting,mopping, etc.

Mixing
UNIV®-SM requires 20% ofNormal Water by weight of material (Example-20kg Bag requires 4.0 to 4.5 Litre ofWater)
Mix UNIV®-SM to the measured quantity of water using mechanical stirring for 2-3 minutes to ensure a consistentlump free mixture

Application- UNIV®-SM on both surfaces using 6 mm notch or mortar trowels spatula.
Place the stone / marble on the surface then move it in perpendicular direction to notches.
Tap the stone / marble gently using wooden block or rubber mallet. Remove the excess adhesive using damp cloth / sponge.

Curing
Due to Silica Base compound the temperature of bonding agent low & it gives fast curing, Its Required time for Settlement is 24 Hr.

Precaution –safety
As per health & safety rules. Use safety accessories required to be used, would include:
a) Safety gloves
b) Safety goggles
c) Dust & nose mask
d) Helmet

In case of accidental contact with eyes of either dry or wet mix, immediately wash your hands; make sure your hands are clean and then wash your eyes with clean water and if required, seek medical assistance.

Avoid breathing dust.
DISCLAIMER
All results and facts stated in this document are applicable under normal conditions and when products are used according to the provided instructions and guidelines. UNIV® CHEMICAL & ADHESIVES assumes no responsibility for deviations or dissatisfaction due to environmental, climatic, temperature, or humidity factors, or due to consumer usage methods.

Copyright @ 2023 UNIV® CHEMICAL & ADHESIVES
